Name: Challenger CMC 600HF Cone Crusher
SKU: CMC600HF
Price: 9999999.0 MYR
Availability: InStock

Challenger CMC 600HF Cone Crusher

Product Details

Weight: 85 000.00 kg

Product Information

The Challenger CMC 600HF is suitable for use as a tertiary crusher.

Supplied with feed hopper with volume of 6.3m3.
Supplied with 1 unit x HPY600 cone crusher with 1 unit x 450kW electrical motor.
Supplied with Weichai 650kW engine.
Supplied with feed conveyor of 1,200mm width.
Supplied with main discharge conveyor of 1,200mm width.
Equipped with Smart Diesel-Electric capability for direct connection to government supplied electrical grid (if required) or external diesel generator (if required).
Equipped with Intelligent PLC Automated Control System for easy operations, real-time monitoring and control.
Equipped with portable wireless controller for ease and convenience.
Fitted with discharge conveyors that can folded hydraulically for convenient transportation.
Capacity: 515TPH @ CSS 25mm
Hopper Feed Height: 4.246 mm
Machine Weight: 85,000 kg
External Dimensions: 18,576 mm x 5,909 mm x 6,162 mm
Transport Dimensions: 19,176 mm x 3,650 mm x 4,900 mm

Product Features

SMART DIESEL-ELECTRIC DRIVE

Besides a high performance and powerful Weichai diesel engine onboard electrically driving the crushers and conveyors, CMC Mobile Crushing & Screening Plants are able to be connected to the government supplied electrical grid. This flexibility results in a highly reliable, operationally economical, and environmentally conscious crushing & screening operation.

LARGE FEED HOPPER

Maximised productivity and trouble-free feeding thanks to the high-capacity feed hopper. In addition, in some models, the hopper volume may be optionally increased by hydraulically extending the hopper walls.

SELF-CLEANING OVERBAND MAGNET

Installed as standard preventive safety equipment in all Trimax Challenger CMC Mobile Jaw Crushers and Horizontal Shaft Impactors to effectively remove unwanted tramp iron from the main discharge conveyor, the self-cleaning overband magnet ensures uninterrupted optimal production of the entire crushing line.

INTELLIGENT PLC WITH WIRELESS REMOTE CONTROL

A simple yet intuitive PLC system guarantees the user optimal control over the initial set-up once the plant arrives on site and during subsequent operation, even via a wireless remote control.

ROBUST STRUCTURAL STEEL CHASSIS

A strong yet compact steel chassis is crucial for the plant to withstand all the tough load-bearing pressures it expects to encounter during normal operations.

HEAVY DUTY TRACKS

Reliable heavy duty tracks that offer superior grip in muddy conditions enable stability and flexible mobility within the site.
